INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page A.21
November 21, 2008
Oct.
Label
429
Parameter
Signal
Format
Units
Pos.
Sense
Range (r)
Sig.
Bits
Res. (r)
SDI
Pres.
Nom. Tx
(a)
017 Selected
Runway
Heading (j)
BCD Degree (c) +359.9 4 0.1 Y 200
033 Landing
System
Mode/
Frequency (j)
BCD N/A N/A N/A N/A N/A Y 200
045 Message
Block Start
(j)
BLOCK N/A N/A 8192 N/A N/A Y Burst (p)
046 Message
Block Body
(j)
BLOCK N/A N/A N/A N/A N/A Y Burst (p)
054 (e) SBAS Range
Offset
BNR Meters + ±4096 20
0.00391
N 1000 (b)
055 (e) SBAS
Ionospheric
Offset
BNR Meters + ±4096 20
0.00391
N 1000 (b)
056 (e) URA Offset
(j)
BNR Meters + ±128 8 0.5 Y 1000 (b)
057 (e) User Range
Accuracy
BNR Meters (c) 8192 17 0.0625 Y 1000 (b)
060 Meas Status
(j)
DISC N/A N/A N/A N/A N/A Y 1000 (b)
061 Pseudo-
Range
BNR Meters + ±268,435,456 20 256 N 1000 (b)
062 Pseudo-
Range Fine
BNR Meters (d) 256 11 0.125 Y 1000 (b)
063 Range Rate BNR m/s + ±4096 20
0.00391
N 1000 (b)
064 Delta-Range BNR Meters + ±4096 20
0.00391
N 1000 (b)
065 SV Position
X
BNR Meters ECEF ±67,108,864 20 64 N 1000 (b)
066 SV Position
X Fine
BNR Meters (d) 64 14
0.00391
Y 1000 (b)
070 SV Position
Y
BNR Meters ECEF ±67,108,864 20 64 N 1000 (b)
071 SV Position
Y Fine
BNR Meters (d) 64 14
0.00391
Y 1000 (b)
072 SV Position
Z
BNR Meters ECEF ±67,108,864 20 64 N 1000 (b)
073 SV Position
Z Fine
BNR Meters (d) 64 14
0.00391
Y 1000 (b)
074 UTC
Measure
Time
BNR Second (c) 10 20
9.54 us
N 1000 (b)
Figure A-13. ARINC Output Data (GLS bus) (Sheet 1 of 4)
Note: The GLS busses operate at high speed (100 KB/sec) only
34-52-81-1
