CMC electronic Esterline CMA-5024 User Manual

INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page E.3
November 21, 2008
APD CID part number: 169-615462-XXX
APD Configuration number: ____
Automatic
SBAS PA
Mode Control
Automatic entry/exit of
SBAS PA mode.
Commanded entry/exit of
SBAS PA mode.
Automatic KH
Selection
Automatic K
H selection for
the SBAS-based
Protection Level used in
the HIL output label on the
GLS bus based on SBAS
PA mode.
Fixed K
H value of 6.18 for the
SBAS-based Protection
Level used in the HIL output
label on GLS bus.
Measurement
Block Integrity
Output only measurements
with integrity as part of the
measurement block.
Output of measurements not
subject to availability of
integrity.
Air/Ground
Discrete Open
in Air
Air/Ground Discrete pin
open indicates 'in air';
ground indicates 'on
ground'.
Air/Ground Discrete pin open
indicates 'ground'; ground
indicates 'in air'.
Data-
Concentrator
DME/ILS
Bridge
ILS data received on the
DME input(s) is
substituted/passed through
on the DME Look-Alike
busses.
ILS data received on the
dedicated ILS input(s) is
substituted/passed through
on the ILS Look-Alike
busses.
ILS Pass-
Through SSM
to NCD
The SSM of all pass-
through labels received on
ILS Input busses are
output with SSM set to
NCD unless at Functional
Test.
The SSM of all pass-through
labels are unchanged.
DME Pass-
Through SSM
to NCD
The SSM of all pass-
through labels received on
DME Input busses are
output with SSM set to
NCD unless at Functional
Test.
The SSM of all pass-through
labels are unchanged.
Left Unit APD
Defined
APD parameters specific
to the left unit are defined.
APD parameters specific to
the left unit are not defined.
Right Unit APD
Defined
APD parameters specific
to the right unit are
defined.
APD parameters specific to
the right unit are not defined.
Center Unit
APD Defined
APD parameters specific
to the center unit are
defined.
APD parameters specific to
the center units are not
defined.
Command
Summary Word
on FMS inputs
A Command Summary
Word is accepted on any
of the IRS/FMS and
FMS/DADS input busses.
A Command Summary Word
is ignored on any of the
IRS/FMS and FMS/DADS
input busses.
SBAS
Corrections on
Labels
061&062
Measurement block
Pseudo-Range data on
labels 061&062 can
include SBAS corrections.
Measurement block Pseudo-
Range data on labels
061&062 never include
SBAS corrections.
