INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page E.8
November 21, 2008
APD CID part number: 169-615462-XXX
APD Configuration number: ____
Parameter When Selected (On) Setting* Notes
033 (ILS) ILS/VOR Frequency
034 (VOR)
017 (BCD) Selected Runway
Heading
105 (BNR)
263 & 264 (ILS) Ground Station Identifier
(ILS/VOR)
242 & 244 (VOR)
201 (BCD)
202 (BNR)
Distance to LTP/FTP
(DME data)
214 (BNR – Precise DME)
002 (BCD) LTP/FTP Time-To-Go
(DME data)
252 (BNR)
012 (BCD) LTP/FTP Range Rate
(DME data)
117 (BNR – Precise DME)
246 & 247 Ground Station Identifier
(DME data)
300
Table 5 - GLSSU Selectable ILS & DME ARINC 429 Labels
*1 = Selected/On 0 = Deselected/Off
For GLSSU Part Number 100-601967-XXX
34-52-81-1
