CMC electronic Esterline CMA-5024 User Manual

INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page G.2
November 21, 2008
LENGTH
(BYTES)
FIELD VALUE SCALE OFFSET HEX
1 Message Identifier 240 F0
3 Station Identifier XLS1 60C4F1
1 Message Type 4 04
1 Message Length 50 32
MESSAGE
HEADER
1 ProviderID/OperType 00/00 00
4 Airport ID CYKY 03190B19
1 Runway Letter/Number 01/25 59
1 Route/ Appr Descriptor 01/01 09
1 RefPathSelector 3 03
4 RefPathID WVBA 17160201
4 Latitude LTP 43.4660402777778 7200000 0 12A75262
4 Longitude LTP -80.36581 7200000 0 DD82BF98
2 Height LTP 285.4 10 512 1F26
3 Delta Latitude FPAP -0.0104615277777778 7200000 0 FED9C5
3 Delta Longitude FPAP -0.0307990277777778 7200000 0 FC9DC7
2 Units (F or M) / TCH F/50 10/20 0 01F4
2 GPA 3 100 0 012C
1 CW 106.75 4 -80 6B
1 Offset 616 0.125 0 4D
1 HAL 20 5 0 64
1 VAL 50 5 0 FA
4 FAS CRC 4C6FAD52
MESSAGE
BODY
4 Message CRC 1BF1C5B3
MESSAGE CRC
34-52-81-1
