5.1 Default configuration
5.1.1 Binary inputs
Number Description Configured function
BIN1 Generator circuit breaker feedback GCB FEEDBACK (PAGE 556)
BIN2 Mains circuit breaker feedback MCB FEEDBACK (PAGE 560)
BIN3 Emergency stop button EMERGENCY STOP (PAGE 554)
BIN4 Access lock keyswitch ACCESS LOCK (PAGE 525)
BIN5 Switch controller to OFF mode REMOTE OFF (PAGE 564)
BIN6 Switch controller to TEST mode REMOTE TEST (PAGE 565)
BIN7 Suppression of alarms SD OVERRIDE (PAGE 565)
BIN8 Free slot NOT USED (PAGE 561)
5.1.2 Binary outputs
Number Description Function
BOUT1 Starter motor control STARTER (PAGE 633)
BOUT2 Fuel solenoid valve FUEL SOLENOID (PAGE 602)
BOUT3 Indication of breaker state GCB CLOSE/OPEN (PAGE 604)
BOUT4 Indication of breaker state MCB CLOSE/OPEN (PAGE 614)
BOUT5 Activation of any devices before start PRESTART (PAGE 621)
BOUT6 Gen-set can be connected to load READY TO LOAD (PAGE 623)
BOUT7 Indication of unconfirmed alarm ALARM (PAGE 582)
BOUT8 Free slot NOT USED (PAGE 620)
