Hardware Installation 2-11
Compaq Confidential – Need to Know Required
Writer:
John Turner
Project:
Compaq Server Console Switch User Guide
Comments:
Part Number:
141555-002
File Name:
c-ch2 Hardware Installation.doc
Last Saved On:
8/22/00 10:26 AM
When using the template on the back of the rack, mark the rack at the top of
the template to help align the next component.
Figure 2-13. Measuring with the template
Attaching the adjustable rack-mounting brackets
To attach the adjustable rack-mounting brackets:
1. Loosely attach the wing nuts to allow adjustment of the length of the
rails to fit your rack.
1
2
Figure 2-14. Adjusting the length of a rack-mounting bracket
