ADVANCED MENUS
COMMANDS SETUP
Scan
Names
OSD
Flag
Devices
Security
Broadcast
Figure 5-3. Advanced Menus, Setup
The Simplified OSD Advanced Menus screen appears showing the commands
listed under the Commands menu. Highlighting Setup shows screen selections
available for configuring your switch. Moving the highlight with the arrow
keys or mouse in either menu selects a specific command or menu screen.
NOTE:
Broadcast
is not an available option for the 2-Port switch.
Exiting the Simplified OSD
To exit the Simplified OSD, press Esc.
Selecting Computers
Use the Simplified OSD menus to switch computers, that is, to select which
computer receives commands from and displays output to the console. When
you select a computer, the switch reconfigures the keyboard and mouse for the
selected computer using the settings stored in its memory. The current
information (for example, the state of the Caps Lock key) is maintained for
each computer in the system. When configuration is complete, the video
output of the selected computer passes to the monitor.
