Compaq EO1002 User Manual

Compaq Confidential – Need to Know Required
Writer:
John Turner
Project:
Compaq Server Console Switch User Guide
Comments:
Part Number:
141555-002
File Name:
i-appc Specifications.doc
Last Saved On:
8/22/00 10:42 AM
Appendix
C
Specifications
Table C-1
Compaq Server Console Switch 2-Port Specifications
Dimensions
Height 1.71 in (4.34 cm)
Depth 7.0 in (17.8 cm)
Width 10 in (25.4 cm)
Weight 3.25 lbs. (1.47 kg)
Input Power Requirements
Rated Voltage 100 – 240V AC
Rated Frequency 50 – 60 Hz
Rated Input Current .5 - .25A
Temperature Range
Maximum Ambient Operating Temperature 50
o
– 104
o
F (10
o
– 40
o
C)
Ambient Storage and Shipping Temperature -40
o
– 185
o
F (-40
o
– 85
o
C)
Maximum Internal Rack Temperature for the
Switch Box
122
o
F (50
o
C)
continued

Compaq EO1002 Specifications

General

Brand	Compaq
Model	EO1002
Category	Switch
Language	English
