Table 4-1
Conventions for Navigating OSD Menus
Item Function
Mouse
Left mouse button Activates commands, highlights line items, and
repositions OSD menus on the desktop (click and drag the
title bar).
Right mouse button Closes the current screen and returns to the previous.
Exits OSD from the Main screen.
Keyboard
Print Scrn
Opens the OSD Selection screen.*
Page Up/Page Down
Pages up and down through the name and port lists.
Enter
Completes switch operation on the Main screen and exits
OSD menus.
Caps Lock
Disabled. (Use
Shift
to change case.)
Esc
Closes the current screen and returns to the previous.
Exits OSD from the Main screen.
Alt
Use in combination with underlined letter to open menus
or execute actions.
Alt
+
X
Closes the current screen.
F1
Opens online help.
Screen
Pages up and down through the name and port lists.
Closes the current screen and returns to the previous
screen without changing settings.
Opens Online Help for each screen.
Accepts changes, closes the current screen, and returns
to the previous screen.
*NOTE:
To print a screen, see “Performing a Screen Capture” in this chapter.
Once the OSD is activated by pressing Print Scrn, you can use the mouse
instead of the arrow keys to highlight menu options.
