4-18 Compaq Server Console Switch User Guide
Compaq Confidential – Need to Know Required
Writer:
John Turner
Project:
Compaq Server Console Switch User Guide
Comments:
Part Number
1141555-002
File Name:
e-ch4 Using the OSD.doc
Last Saved On:
8/22/00 10:37 AM
Table 4-12
Flag Screen Functions
Field/Button Select/Click to… Alternate Method
Name
Identify computers by name
Press
Alt
+
N
Port
Identify computer by port
Press
Alt
+
P
Displayed
show flag at all times
Press
Alt
+
D
Timed
display flag for only 5 seconds after switching
Press
Alt
+
T
Flag 1, 2, 3, 4
select a color palette
Press
Alt
+
1
,
2
,
3
,
or
4
Opaque
have the flag cover the desktop image
Press
Alt
+
A
Transparent
have the desktop image seen through the flag
Press
Alt
+
R
Set Position
position flag on the screen
Press
Alt
+
S
OK
save current settings and return to the
previous screen
Press
Alt
+
O
To position the status flag on the desktop:
1. Click Set Position.
2. Click and drag the title bar to where you want the status flag to display
on the desktop.
3. Click X to exit the dialog box. The setting is saved.
