Compaq EO1002 User Manual

Using the On-Screen Display 4-21
Compaq Confidential – Need to Know Required
Writer:
John Turner
Project:
Compaq Server Console Switch User Guide
Comments:
Part Number:
1141555-002
File Name:
e-ch4 Using the OSD.doc
Last Saved On:
8/22/00 10:37 AM
4. Choose Energy if your monitor is Energy Star compliant, or Screen if it
is not.
CAUTION:
Monitor damage can result from use of Energy Mode with monitors
that are not Energy Star compliant. DO NOT use this mode if your monitor is not
Energy Star compliant.
5. Click Test to view the screen saver.
6. Click OK.
To blank the monitor without locking the console:
1. Delete the text in the New field and leave the box blank.
2. Select Enable Screen Saver.
3. In the Time Delay field, type the number of minutes (from 1 to 254) that
you want to delay activation of the screen saver.
4. Choose Energy if your monitor is Energy Star compliant, or Screen if it
is not.
CAUTION:
Monitor damage can result from use of Energy Mode with monitors
that are not Energy Star compliant. DO NOT use this mode if your monitor is not
Energy Star compliant.
5. Click Test to view the screen saver.
6. Click OK.
IMPORTANT:
This action overrides the use of a password. Pressing any key on the
keyboard unlocks the console. Your system IS NOT secure.
To disable the screen saver:
1. In screen saver mode, press any key on the keyboard then type your
password if your console is password protected.
2. Press Print Screen to display the Main screen.
3. Click Setup | Security.
4. Type your password in the New field.
5. Deselect Enable Screen Saver.
6. Click OK.

Compaq EO1002 Specifications

General

Brand	Compaq
Model	EO1002
Category	Switch
Language	English
