Compaq EO1002 User Manual

Using the Simplified OSD 5-7
Compaq Confidential – Need to Know Required
Writer:
John Turner
Project:
Compaq Server Console Switch User Guide
Comments:
Part Number:
141555-002
File Name:
f-ch5 Using the Simplified OSD.doc
Last Saved On:
8/22/00 10:40 AM
OSD ATTRIBUTES
Resolution 320
Height 56
Horizontal 3
Vertical 4
Background 7
Highlight 6
Text 0
Delay Time 0
Order PORT
Figure 5-5. OSD Attributes screen
3. Highlight the settings you want to change and use the + or – keys to
obtain the desired value.
As you select different values, the effect of the changes is reflected
immediately on the display. Table 5-1 describes each of the available
menu attributes.
NOTE:
While changing Simplified OSD attributes, it is possible to scramble the menu and
screens, making it difficult to correct the problem. If this occurs, reset the switch to its
default Simplified OSD values by pressing:
Esc
+
Esc
+
Print Scrn
+
F10
+
Y
+
Enter
4. Press Esc to save the settings and exit the menu.
or
F10 to restore default settings.
or
Esc to exit the menu without saving the settings.
