REMEMBER TO INSTALL THE FIXED RAMP, BEING
CAREFUL TO ENSURE PROPER RUNNING
CLEARANCES AT THE PLATFORM.
NOTE
The proper operation of an SE Model depends upon proper installation in the field. Enough
supports for the side walls and gates are needed for proper operation. Inspect the site
and rigidly fix the assembly to the floor and walls. It may be necessary to add additional
bracing, especially at Panel C1.
IT IS MOST IMPORTANT TO ADD ADDITIONAL
BRACING AT THE TOP GATE POSTS.
36
Figure # 22 Semi-Enclosure Assembly Drawing - Enclosure and Unit in Pit
