Cornelius FCB POST-MIX DISPENSER - Page 100

2813 92
1
2
2
3
4
5
6
FIGURE 39. BEATER MOTOR DRIVE SHAFT/SEAL ASS’Y
Item
No. Part No. Name
3193 Rear Seal Ass’y
1 3156 Drive Shaft
2 2463 Bearing with Setscrews
Item
No. Part No. Name
3 2360 O-Ring, 1.86 I.D. By .139 C.S.
4 2583 Retaining Ring
5 2731 O-Ring, .671 I.D. By .139 C.S.
6 2591 Housing
