Cornelius FCB POST-MIX DISPENSER - Page 85

77
2813
FCB POST-MIX DISPENSER (cont’d)
Item
No.
Part No. Name
1 325457 Blade, Scraper
2 3432 Body, Beater
3 326002 Tube Kit, Drain Tube (Not Shown; See
Figure 29)
4 324218 Tube, .156 I.D. By 3-In. Long, CO
2
Regulator to Tee
324219 Tube, .156 I.D. By 1-In. Long, CO
2
Regulator to Tee
324222 Tube, .156 I.D. By 2-In. Long, Tee to Tee
5 324220 Tube, .156 I.D. By 11-In. Long, Regulator
Tee to Drain Tee
6 317528 Fitting, Tee, 1/8-Barb
7 300393 Fitting, Tee, 3/16-Barb By 3/8-Barb
8 324221 Tube, .312 I.D. By 6-In. Long, Drain
9 326079 Cable Ribbon, Display Board
10 1317 Filter, Solenoid
11 317015 O-Ring, .239 I.D. By .070 C.S.
12 311908 Clamp, .437 O.D. Tube
13 2392 Bushing, Flange, .501 I.D.
14 324244 Fitting, Tee, 5/16-Barb
15 178025-100 Tapered Gasket, White
16 187462 Tube, .312 I.D. By 20-In. Long, Drain
17 325957 Support, P.C. Board
18 326078 P.C. Board, Display
19 320737 Washer, .343 I.D. (Water Cooled)
20 325982 Cup Rest (2-Flavor)
325992 Cup Rest (4-Flavor)
21 325983-039 Drip Tray (2-Flavor)
325990-039 Drip Tray (4-Flavor)
22 325986 Support, Drip Tray
23 325984 Frame, Drip Tray (2-Flavor)
325991 Frame, Drip Tray (4-Flavor)
24 326151-073 Plate, Backup, Display (2-Flavor)
326037-073 Plate, Backup, Display (4-Flavor)
25 176193 Fitting, 7/16-20
26 2509 Plate, Brix Bracket Support (4-Flavor)
27 3193 Drive Shaft/Seal Ass’y (See Figure
28 319739 Transformer, 240V. 50/60HZ.
29 2469 Retainer, Module
30 324171 Relay, 10-Amp 230V. 50/60HZ. (Klauber)
Item
No. Part No. Name
31 189429 Hex Nut, 1/4-20
32 200498-003 Hex Nut, No. 8-32
33 3108 Thread Rolling Screw, Phil Truss Hd.,
No. 10-24 By 3/4-In. Long
34 343304 Washer, .204 I.D.
35 319941 Thread Rolling Screw, Hex Washer Hd.,
No. 8-32 By 3/8-In. Long
36 325282 Machine Screw, Hex Washer Hd., No.
8-18 By 1/2-In. Long
37 310461 Thread Rolling Screw, Phil Pan Hd., No.
8-32 By 3/8-In. Long
38 320106 Thread Rolling Screw, Phil Pan Hd., No.
6-32 By 1-In. Long
39 322967 Washer, .142 I.D.
40 325721-068 Panel, Top (2-Flavor)
1425 Panel, Top, Stainless Steel (2-Flavor)
326026-068 Panel, Top (4-Flavor)
1426 Panel, Top, Stainless Steel (4-Flavor)
41 3004 Access Door (2-Flavor)
2999 Access Door (4-Flavor)
42 325962-040 Touch Switch
43 398024-603 Hex Nut, No. 10-24
44 3796 Frame (2-Flavor)
3797 Frame (4-Flavor)
45 3007 Panel, Lower Front (2-Flavor)
3050 Panel, Lower Front, Stainless Steel
(2-Flavor)
3000 Panel, Lower Front (4-Flavor)
3051 Panel, Lower Front, Stainless Steel
(4-Flavor)
46 325725 Bracket, Regulator (2-Flavor)
325556 Bracket, Regulator (4-Flavor)
47 186770 Machine Screw, Phil Rd. Hd., No. 10-24
By 5/8-In. Long
48 3008 Panel, Drip Tray (2-Flavor)
3001 Panel, Drip Tray (4-Flavor)
49 325731-068 Trim, Lower Front (2-Flavor)
1427 Trim, Lower Front, Stainless Steel
(2-Flavor)
326028-068 Trim, Lower Front (4-Flavor)
1428 Trim, Lower Front, Stainless Steel
(4-Flavor)
50 325981-069 Holder, Flavor Tab (2-Flavor)
326082-069 Holder, Flavor Tab (4-Flavor)
