FCB POST-MIX DISPENSER (cont’d)
Item
No.
Part No. Name
51 0157 Panel, Right-Hand Side
1422 Panel, Right-Hand Side, Stainless Steel
52 0156 Panel, Left-Hand Side
1421 Panel, Left-Hand Side, Stainless Steel
53 321503 Catch Bullet
54 320754 Tube, Drain, 2-1/4-In. Long, Stainless
Steel
55 320776 Strap, Tube
56 325557 Trim, Foam Pack (4-Flavor)
57 325701 Extension, Foam Pack (2-Flavor)
326049 Extension, Foam Pack (4-Flavor)
58 0831 Retainer, Syrup Lines
59 316753 Push-on Nut
60 326106 Door Ass’y, Freeze Cylinder (See Figure
22)
61 320553-001 Hex Nut, 7/16-14
62 320916 Washer, .450 I.D.
63 326128 Shroud, Condenser (Air Cooled)
64 326097 Regulator Ass’y, CO
2
(2-Flavor; See
Figure 24)
326099 Regulator Ass’y, CO
2
(4-Flavor; See
Figure 24)
65 2467 Foam Pack
66 319357 Motor, Condenser Fan, 230V. 1550RPM
(Air Cooled)
67 319358 Fan, Condenser Motor, 6-Blade
(Air Cooled)
68 325711-011 Bracket, Motor (Air Cooled)
69 2517 Wire Harness, Input (Not Shown)
70 325192 Bushing (4-Flavor)
71 325740-039 Housing, Display (2-Flavor)
326081 Housing, Display (4-Flavor)
72 186154 Machine Screw, Phil Pan Hd., No. 8-36
By 3/8-In. Long (Air Cooled)
73 2104 Condenser (Air Cooled)
0669 Condenser Coil (Water Cooled)
74 2480 Bracket, Carbonator (2-Flavor)
2481 Bracket, Carbonator (4-Flavor)
75 326090 Strap, Fan Motor (Air Cooled)
76 325940 Relay, Start, Compressor, 230V. 60HZ.
35Amp
Item
No. Part No. Name
77 325938 Capacitor, Start, 250V. 60HZ.
78 325939 Capacitor, Run, 440V. 60HZ.
79 325776 Pressure Switch, CO
2
80 150918 Machine Screw, Sl Truss Hd., No. 8-32
By 3/8-In. Long
81 2496 Wire Harness, Output (Not Shown)
82 325644 Lug, Ground
83 325145 Washer, .205 I.D.
84 325069 Machine Screw, Sl Truss Hd., No. 10-24
By 1/2-In. Long
85 320620 Contactor, 208/240V. 50/60 HZ.
86 187552 Machine Screw, Phil Rd. Hd., No. 8-32
By 1/4-In. Long
87 174061-196 Tube Ass’y, .265 I.D. By 96-In. Long,
CO
2
Cylinder to CO
2
Regulator (See
Figure 30)
88 325956 Strap, Capacitor (2-Flavor)
326035 Strap, Capacitor (4-Flavor)
89 326000 Compressor Kit, 2H.P. 230V. 60HZ.
324233 Compressor Kit, 2H.P. 230V. 50HZ.
90 313802 Bushing, .875 Dia.
91 325635 Cover, Control Box (2-Flavor)
326029 Cover, Control Box (4-Flavor)
92 311304 Tapered Gasket, Black
93 325558 Tube Ass’y, .250 I.D. By 40-In. Long,
CO
2
Regulator to Carbonator (See
Figure 31)
94 319871 Dryer
95 2492 Tube Ass’y, With Shutoff Valve, Carb
Water (See Figure 32)
96 2495 Tube Ass’y, .250 I.D. By 18-In. Long,
Water Pump to Carbonator (See Figure
33)
97 326071 Expansion Valve, Refrigeration
98 0924 Panel, Back (2-Flavor)
2776 Panel, Back, Stainless Steel (2-Flavor)
2471 Panel, Back (4-Flavor)
2777 Panel, Back, Stainless Steel (4-Flavor)
99 325621-011 Receiver
100 321818 Button Plug, 1-1/8 Dia.
101 309338-011 Clip, Sensor, Expansion Valve
102 309338-012 Clip, Sensor, Thermostat
To Next Page
