Cornelius FCB POST-MIX DISPENSER - Page 87

79
2813
FCB POST-MIX DISPENSER (cont’d)
Item
No.
Part No. Name
103 320940 Machine Screw, Hex Washer Hd., No.
10-16 By 5/8-In. Long
104 3238 Bracket, Beater Motor
105 324120 Motor, 1/4H.P. 220V. 60HZ (Klauber)
2472 Motor, 1/4H.P. 230V. 50HZ (Klauber)
3471 Motor, 1/8H.P. 208/240V. 50/60HZ
(Emerson)
2091 Motor, 1/4H.P. 220V. 60HZ (Fasco)
2108 Motor, 1/4H.P. 230V. 50HZ (Fasco)
106 325738 Control Box, Lower (2-Flavor)
326038 Control Box, Lower (4-Flavor)
107 326073-011 Thermostat Sensor
108 325767 Cover, Control Box, Upper (2-Flavor)
326031 Cover, Control Box, Upper (4-Flavor)
109 312251 Thread Rolling Screw, Phil Pan Hd., No.
10-24 By 3/8-In. Long
110 324184 Control Box, Upper (2-Flavor)
0642 Control Box, Upper (4-Flavor)
111 0150 Fan, 230V. 9-Watt
112 320767 Machine Screw, Phil Pan Hd., No. 10-24
By 3/8-In. Long
113 324136 Board, P.C.
114 1020 Wire Harness, Circuit Board
(Not Shown)
115 309854 Clamp, .409 O.D. Tube
116 326136 Carbonator Tank Ass’y (See Figure 25)
117 325998 Cable, Circuit Board
118 3159 Pressure Switch, Water
119 2494 Pump and Motor Ass’y, 115V. 60HZ
(See Figure 26)
2493 Pump and Motor Ass’y, 230V. 50HZ
(See Figure 26)
120 318976 Machine Screw, Sl. Hex Hd., 1/4-20 By
1/2-In. Long
121 325925 Support, Board
122 326076 Board, Circuit, Motor No. 1
123 326077 Board, Circuit, Motor No. 2
124 311855 J-Nut, 1/4-20
125 186148 Washer, .319 I.D.
126 325529 Grommet, Compressor
127 325530 Spacer, Compressor
Item
No. Part No. Name
128 186146 Hex Nut, 5/16-18
129 318418 Washer, .312 I.D.
130 176272-396 Tube Ass’y, .375 I.D. By 96-In. Long,
Water Inlet (2-Flavor; See Figure 30)
2593 Tube Ass’y, Water Inlet (4-Flavor; See
Figure 34)
131 325673 Washer, .384 I.D.
132 320899 Cap Screw, Hex Hd., 5/16-18
By 4/4-In. Long
133 317974 Deflector, Water, Carbonator
134 326113 Tube Ass’y, Syrup (See Figure 35)
135 3787 Coupling, Shaft
136 326111
Sold-out Switch
137 311764-001 Check Valve Ass’y (See Figure 27)
138 178025-200 Tapered Gasket, Red
139 325507 Bracket, Blender
140 325716 Support, Blender (2-Flavor)
325508 Support, Blender (4-Flavor)
141 324116 Washer, .625 I.D.
142 SK324047 Tank, Blender
143 186570 Strain Relief
144 343487 Machine Screw, Phil Pan Hd., No.
8/32-By 1/2-In. Long
145 315925 O-Ring, 1.609 I.D. By .139 C.S.
146 315931 O-Ring, .364 I.D. By .070 C.S.
147 325288 Float Switch, Blender
148 324048 Holder, Float Switch
149 2487 Solenoid Valve Ass’y, Syrup
(See Figure 28)
150 1578 Tube Ass’y, Blender to Freeze Cylinder
(See Figure 36)
151 324115 Retaining Ring, Holder
152 2491 Tube Ass’y Water Solenoid to Blender
(See Figure 37)
153 326098 Tube Ass’y .250 I.D. By 48–In. Long,
CO
2
Regulator to Blender
(See Figure 38)
154 183008 O-Ring, .489 I.D. By .070 C.S.
