15. MISSING LINE MEASUREMENT
The Missing Line Measurement (MLM) routine is used to measure the slope distance,
horizontal distance, and horizontal angle from one point to another with one point
being a reference point or starting point. This is done without moving the instrument.
z The last measured point may be switched to the starting point for continuous
measurements.
z If heights are going to be compared, the target height and instrument heights must be set.
z Measurements may be displayed in %gradient from point to point.
15.1 Measuring the distance between 2 or more points
O
eratin
Ke
s Dis
la
1． Sight the starting position, and press
MEAS
【DIST】 in the first page of Meas
Mode to begin measurement.
The measured values are displayed.
Press 【STOP】to stop measurement.
S 10.567m
【DIST】
ZA 70°11′57″
HAR 135°31′27″ P1
DIST SHV HSET EDM
50
To Next Page
