CST/BERGER CST205 - Setting-Out Line

19.3 Setting-out line
The Setting-out line “Line” measurement tells how far horizontally the measured point
is from the baseline and how far vertically the measured point is from the connected
line. The baseline can be offset in a horizontal direction if necessary. Before performing
setting-out line “Line”, the baseline must be defined.
Origin
Measured point
Measured point
Height Difference
Profile View
Offset
Length
Offline(-)
2nd Pt
67
