2 — INSTALLATION & WIRING: Low Current Connections
* e related VCL columns are vital when writing VCL code (see Section 8).
VCL “functions” are used to access the various I/Os; VCL “references” are
predefined names for specific pins.
Table 2 Low Current Connections
related vcl
*
pin name description
functions references
1 KSI Keyswitch input. Keyswitch_Voltage
Provides logic power for
the controller and power
for the coil drivers.
2 Prop. Driver Proportional driver. Automate_PWM Sw_13
This is a coil driver with Put_PWM PWM5
current control capability PD_Current
typically used for a PD_Output
proportional valve on a PD_Throttle
hydraulic manifold. VCL_PD_Throttle
Can also be used as a
digital input.
3 Driver 4 Generic driver #4; can Automate_PWM Sw_12
also be used as a digital Put_PWM PWM4
input. Has low frequency PWM4_Output
PWM capabilities.
4 Driver 3 Generic driver #3; can Automate_PWM Sw_11
also be used as a digital Put_PWM PWM3
input. Has low frequency PWM3_Output
PWM capabilities. Typically
used for pump contactor.
5 Driver 2 Generic driver #2; can Automate_PWM Sw_10
also be used as a digital Put_PWM PWM2
input. Has low frequency PWM2_Output
PWM capabilities and
a slightly higher current
rating.Typically used for
electromagnetic brake.
6 Driver 1 Generic driver #1; can Automate_PWM Sw_9
also be used as a digital Put_PWM PWM1
input. Has low frequency Set_Interlock PWM1_Output
PWM capabilities. Clear_Interlock Interlock_State
Typically used for main Main_State
contactor.
7 I/O Ground Input and output ground
reference.
8 Switch 2 Can be used as generic Sw_2
Analog 2 switch input #2 or as Analog2_Input
generic analog input #2. Motor_Temperature
Typically used as the
motor temperature
analog input.
9 Switch 3 Generic switch input #3. Sw_3
Typically used as the
interlock switch.
10 Switch 4 Generic switch input #4. Sw_4
11 Switch 5 Generic switch input #5. Sw_5
To Next Page
