Curtis 1232E/34E/36E/38E & 1232SE/34SE/36SE Manual, os 30
24 NOVEMBER 2015
3 — PROGRAMMABLE PARAMETERS: Fault Checking Parameters
DRIVERS: FAULT CHECKING MENU
ALLOWABLE
PARAMETER RANGE DESCRIPTION
Driver1 Checks Enable On / Off C
Driver1_Checks_Enable On / Off
OptionBits2 [Bit 1]
0x306B 0x00
Driver2 Checks Enable On / Off S
Driver2_Checks_Enable On / Off
OptionBits2 [Bit 2]
0x306B 0x00
Driver3 Checks Enable On / Off S
Driver3_Checks_Enable On / Off
OptionBits2 [Bit 3]
0x306B 0x00
Driver4 Checks Enable On / Off S
Driver4_Checks_Enable On / Off
OptionBits2 [Bit 4]
0x306B 0x00
PD Checks Enable On / Off S
PD_Checks_Enable On / Off
OptionBits2 [Bit 5]
0x306B 0x00
External Supply Max 0 – 200 mA Sets the upper threshold of the combined current of the 5V and 12V
External_Supply_Max 0 – 800 external supplies. At or above this threshold a fault will be created that
0x3046 0x00 can be read by VCL.
External Supply Min 0 – 200 mA Sets the lower threshold of the combined current of the 5V and 12V
External_Supply_Min 0 – 800 external supplies. At or below this threshold a fault will be created that
0x3047 0x00 can be read by VCL.
TheveChecksEnableparametersareusedtoenabledriver
andcoilfaultdetectionattheveindividualdrivers(atPins
J1-6, J1-5, J1-4, J1-3, and J1-2). When a Checks parameter
is enabled, the associated driver, driver wiring, and driver load
are checked to verify that the driver correctly drives the load
both high and low. The checks will occur regardless of the PWM
output of the driver. The checks will detect both open and shorted
conditions. When a fault is detected, the controller opens the
driver and issues a fault code.
If nothing is connected to a driver, its Checks Enable
parameter should be set Off.
 Note:Shortcircuitprotectionisalwaysactiveattheseve
drivers, regardless of how Checks Enable is set.
DRIVERS: PWM FREQUENCY PARAMETER
ALLOWABLE
PARAMETER RANGE DESCRIPTION
PWM Frequency 100–1000Hz ThissingleparameterdenesthefrequencyofDrivers1through4.
PWM_Frequency 100 – 1000
0x3938 0x00
