Curtis 1236SE User Manual

60
Curtis 1232E/34E/36E/38E & 1232SE/34SE/36SE Manual, os 30
24 NOVEMBER 2015
MOTOR: 1-SPM: CHARACTERIZATION TESTS MENU
ALLOWABLE
PARAMETER RANGE DESCRIPTION
Test Enable 0–1 ThisparameterisusedtostarttheSPMmotorcharacterization
SPM_AutoChar_Test_Enable 0 – 1 procedure. See section 6b for the complete description of the
0x3862 0x00 SPMmotorcharacterizationprocedure.
Test Throtte -1 – 1 This parameter is used to verify the direction of the motor during
Test_Throttle -1 – 1 SPMmotorcharacterization.
0x3034 0x00 See section 6b for the complete description of the SPM
 motorcharacterizationprocedureandhowthisparameterisused.
Max Test Speed 500 – 6000 rpm This parameter is used to set the maximum motor speed
SPM_AutoChar_Max_Test_Speed 500 – 6000  allowedduringSPMmotorcharacterization.
0x38C1 0x00 See section 6b for the complete description of the SPM
  motorcharacterizationprocedureandhowthisparameteris
used.
Max Test Current 10 – 30 % This parameter is used to set the maximum motor current
SPM_AutoChar_Max_Test_Current 3277 – 9831  allowedduringSPMmotorcharacterization.
0x38C2 0x00 See section 6b for the complete description of the SPM
  motorcharacterizationprocedureandhowthisparameteris
used.
3 — PROGRAMMABLE PARAMETERS: Motor Parameters
