Curtis 1236SE User Manual

56
Curtis 1232E/34E/36E/38E & 1232SE/34SE/36SE Manual, os 30
24 NOVEMBER 2015
3 — PROGRAMMABLE PARAMETERS: Motor Parameters
MOTOR: 0-ACIM: CHARACTERIZATION TESTS MENU
ALLOWABLE
PARAMETER RANGE DESCRIPTION
Test Enable 0–1 ThisparameterisusedtostarttheACIMmotorcharacterization
IM_AutoChar_Test_Enable 0 – 1 procedure. See Section 6a for the complete description of the ACIM
0x3800 0x00 motorcharacterizationprocedure.
Test Throtte -1 – 1 This parameter is used to change the direction of the motor to the
Test_Throttle -1 – 1 forwarddirectionduringACIMmotorcharacterization.
0x3034 0x00 See Section 6a for the complete description of the ACIM motor
characterizationprocedureandhowthisparameterisused.
Motor Poles 2 – 12 This parameter is used to select the number of poles before
IM_MotorData6 1 – 6 beginningtheACIMmotorcharacterizationprocedure.
0x3805 0x00 See Section 6a for the complete description of the ACIM motor
characterizationprocedureandhowthisparameterisused.
Max Test Speed 500 – 8000 rpm This parameter is used to set the maximum motor speed allowed
IM_AutoChar_Max_Test_Speed 500 – 8000 duringACIMmotorcharacterization.
0x38A0 0x00 See Section 6a for the complete description of the ACIM motor
characterizationprocedureandhowthisparameterisused.
Max Test Current 10 – 100 % This parameter is used to set the maximum motor current allowed
IM_AutoChar_Max_Test_Current 3277 – 32767 duringACIMmotorcharacterization.
0x38A1 0x00 See Section 6a for the complete description of the ACIM motor
characterizationprocedureandhowthisparameterisused.
SlipGain 0.00–200.00 ThisparameterisadjustedduringACIMmotorcharacterization
IM_MotorData8 0 – 20000 to tune the motor to deliver the maximum torque per amp.
0x3819 0x00 See Section 6a for the complete description of the ACIM motor
characterizationprocedureandhowthisparameterisused.
Current Reg Tuning Test Enable 0 – 1 This parameter is used to perform only the current regulation tuning
IM_CR_Tuning_Test_Enable 0 – 1 portionoftheACIMmotorcharacterizationprocedure.
0x388B 0x00
