Curtis 1232E/34E/36E/38E & 1232SE/34SE/36SE Manual, os 30
24 NOVEMBER 2015
Monitor Menu: BATTERY
DISPLAY
VARIABLE RANGE DESCRIPTION
BDI 0 – 100 % Battery state of charge.
BDI_Percentage 0 – 100
0x3308 0x00
Capacitor Voltage
0.0 – 200.0 V Voltageofcontroller’sinternalcapacitorbank
Capacitor_Voltage 0 – 12800 at B+ terminal.
0x324C 0x00
Keyswitch Voltage
0.0 – 105.0 V Voltage at KSI (pin 1).
Keyswitch_Voltage 0 – 10500
0x324D 0x00
Monitor Menu: OUTPUTS, cont’d
DISPLAY
VARIABLE RANGE DESCRIPTION
Ext Supply Current 0 – 200 mA Combined current of the external +12V and
Ext_Supply_Current 0 – 800 +5V voltage supplies (pins 25 and 26).
0x3229 0x00
Pot Low
0.00 – 6.25 V Voltage at pot low (pin 18).
Pot_Low_Output 0 – 1023
0x3203 0x00
4a — MONITOR MENU
