Curtis 1232E/34E/36E/38E & 1232SE/34SE/36SE Manual, os 30
67
24 NOVEMBER 2015
3 — PROGRAMMABLE PARAMETERS: Vehicle Parameters
VEHICLE MENU
ALLOWABLE
PARAMETER RANGE DESCRIPTION
Metric Units On / Off When this parameter is programmed On, the distance variables (Vehicle
Metric_Units On / Off Odometer, Braking Distance Captured, Distance Since Stop, Distance Fine,
OptionBits3 [Bit 5] and the Capture Distance variables) will accumulate and display in metric
0x306C 0x00 units (km, meters, or decimeters). When programmed Off, the distance
variables will accumulate and display in English units (miles, feet, or inches).
Distance variables are displayed in the Monitor » Vehicle menu, page 83.
Speed to RPM
10.0 – 3000.0 This parameter affects the vehicle speed displayed in the Monitor » Motor
Speed_to_RPM 100 – 30000 menu(seepage79),andalsomodiestheVCLvariableVehicle_Speed;
0x304C 0x00 it does not affect actual vehicle performance. The value entered for Speed
to RPM is a conversion factor that scales motor speed to vehicle speed.
KPH to RPM: (G/d)*5305, where G = gear ratio, d = tire diameter [mm].
MPH to RPM: (G/d)*336.1, where G = gear ratio, d = tire diameter [in].
Capture Speed 1 0 – 8000 rpm The controller captures the time it takes the motor to go from 0 rpm to the
Capture_Speed_1 0 – 8000 programmed Capture Speed. The result is stored as “Time to Speed 1”
0x3079 0x00 in the Monitor » Vehicle menu (page 83). This timer starts every time the
motoracceleratesfromzerospeed.
Capture Speed 2 0–8000rpm Thisparameterallowsasecondcapturespeedtobedened,andworks
Capture_Speed_2 0 – 8000 identically to Capture Speed 1. The result is stored as “Time to Speed 2”
0x3886 0x00 in the Monitor » Vehicle menu (page 83).
Capture Distance 1
1 – 1320 The controller captures the time it takes the vehicle to travel from 0 rpm to
Capture_Distance_1 1 – 1320 the programmed Capture Distance. The result is stored as “Time to Dist 1”
0x307A 0x00 in the Monitor » Vehicle menu (page 83). This timer starts every time the
vehicleacceleratesfromzerospeed.
Note: For accurate distance measuring, the Speed to RPM parameter
must be set correctly.
With the Metric Units parameter programmed Off, distance is in units
of feet. With Metric Units programmed On, distance is in units of meters.
Capture Distance 2
 1–1320 Thisparameterallowsasecondcapturedistancetobedened,andworks
Capture_Distance_2 1 – 1320 identically to Capture Distance 1. The result is stored as “Time to Dist 2”
0x3883 0x00 in the Monitor » Vehicle menu.
Capture Distance 3
 1–1320 Thisparameterallowsathirdcapturedistancetobedened,andworks
Capture_Distance_3 1 – 1320 identically to Capture Distance 1. The result is stored as “Time to Dist 3”
0x3884 0x00 in the Monitor » Vehicle menu.
