Curtis 1236SE User Manual

106
Curtis 1232E/34E/36E/38E & 1232SE/34SE/36SE Manual, os 30
24 NOVEMBER 2015
8
8 — VCL
VEHICLE CONTROL LANGUAGE (VCL)
Curtis 1232E/34E/36E/38E and 1232SE/34SE/36SE controllers have a built-in
programmable logic controller with application-specific functions. VCL (Vehicle
Control Language) software provides a way to implement unique and complex
vehicle control functions.
VCL is a simple programming language that will feel very familiar to
anyone who has worked with BASIC, Pascal, or C. Working with VCL requires
the installation of the WinVCL program onto a PC. WinVCL will compile
VCL programs and ash download the software into the controller through the
computer’s serial port. e install process for WinVCL will also install three
important manuals on your PC: the WinVCL User’s Guide, VCL Programmer’s
Guide, and VCL Common Functions Manual. ese manuals, which are in PDF
format, include more detailed information about VCL than is included here.
is section of the manual summarizes VCL and also describes aspects
and functions of VCL that are specic to these E and SE controllers. For a
more complete understanding of the functions and capabilities of VCL, see
the WinVCL User’s Guide, VCL Programmer’s Guide, and VCL Common
Functions Manual.
Summary of VCL Basics
•VCLisnotcase-sensitive:
put_pwm(), Put_PWM(), and PUT_PWM() are identical.
• SpacesinvariablenamesarenotallowedinVCL;useunderscores
in place of spaces.
Example: Forward_Offset is the VCL name for the programmable
parameter Forward Offset.
•Functionsarefollowedbyparentheses;forexample:
Reset_Controller() is a function
Reset_Voltage is a variable.
•Logicalstatementsmustbeinsideparentheses;examples:
IF (setpoint >50)
ELSE IF ((setpoint <20) & (temperature >100)).
•Commentsareprecededbysemicolons.
