Curtis 1236SE User Manual

Curtis 1232E/34E/36E/38E & 1232SE/34SE/36SE Manual, os 30
83
24 NOVEMBER 2015
4a — MONITOR MENU
Note: All vehicle
calculations assume
no tire slippage.
+
Monitor Menu: VEHICLE
DISPLAY
VARIABLE RANGE DESCRIPTION
Vehicle Speed -3276.8 – 3276.7 Vehicle speed, in units of MPH or KPH,
Vehicle_Speed -32768 – 32767 depending on the setting of the Metric
0x320A 0x00 Units parameter (see Program » Vehicle
menu, page 67).
For accurate speed estimates, the
Speed to RPM parameter must be set
correctly (page 67).
Vehicle Odometer
0.0 – 1000000.0 Vehicle distance traveled, in units of miles
Vehicle_Odometer 0 – 10000000 or km, depending on the setting of the
0x3200 0x00 Metric Units parameter (page 67).
For accurate distance measurements,
the Speed to RPM parameter must be set
correctly (page 67).
Vehicle Acceleration
0.000–10.000 g Vehicle acceleration. The Speed to RPM
Vehicle_Acceleration 0–10000 parameter must be set correctly for
0x35C1 0x00 accurate measurement (page 67).
Time to Speed 1 0.00–128.00s Timetakenforthevehicletogofromzero
Time_to_Capture_Speed_1 0 – 32000 rpm to the programmed Capture Speed 1
0x35BF 0x00 (see Program » Vehicle menu, page 67)
during its most recent such acceleration.
Time to Speed 2
 0.00–128.00s Timetakenforthevehicletogofromzero
Time_to_Capture_Speed_2 0 – 32000 rpm to the programmed Capture Speed 2
0x35BB 0x00 (see Program » Vehicle menu, page 67)
during its most recent such acceleration.
Time Between Speeds
0.00 – 128.00 s Time taken for the vehicle to go from
Time_Between_Capture_ 0 – 32000 programmed Capture Speed 1 to
Speeds programmed Capture Speed 2 (see
0x35C4 0x00 Program » Vehicle menu, page 61) during
its most recent such acceleration.
Time to Dist 1
0.00 – 128.00 s Time taken for the vehicle to travel from
Time_to_Capture_Distance_1 0 – 32000 zerorpmtotheprogrammedCapture
0x3612 0x00 Distance 1 (see Program » Vehicle menu,
page 67) during its most recent such trip.
For accurate distance measurements,
the Speed to RPM parameter must be set
correctly (page 67).
Time to Dist 2
0.00 – 128.00 s Time taken for the vehicle to travel from
Time_to_Capture_Distance_2 0 – 32000 zerorpmtotheprogrammedCapture
0x3613 0x00 Distance 2 (see Program » Vehicle menu)
during its most recent such trip.
For accurate distance measurements,
the Speed to RPM parameter must be set
correctly (page 67).
