80
Curtis 1232E/34E/36E/38E & 1232SE/34SE/36SE Manual, os 30
24 NOVEMBER 2015
4a — MONITOR MENU
Monitor Menu: CONTROLLER
DISPLAY
VARIABLE RANGE DESCRIPTION
Current (RMS) 0.0 1000.0 A RMS current of the controller, taking all
Current_RMS 0 – 10000 three phases into account.
0x3209 0x00
Modulation Depth
0.0 100.0 % Percentage of available voltage being used.
Modulation_Depth 0 – 1182
0x3208 0x00
Frequency
-500–500Hz Controllerelectricalfrequency.
Frequency -3000 – 3000
0x3206 0x00
Temperature
-100 300 °C Controller internal temperature.
Controller_Temperature -1000 – 3000
0x322A 0x00
Main State
0 – 10 Main contactor state:
Main_State 0 – 10 0 = open
0x3223 0x00 1 = precharge
2 = weld check
3 = closing delay
4 = missing check
5 = closed (when Main Enable = On)
6 = delay
7 = arc check
8 = open delay
9 = fault
10= closed (when Main Enable = Off).
EMBrake State 0 – 4 EM brake state:
EMBrakeState 0 – 4 0 = engaged
0x3892 0x00 1 = releasing
2 = released
3 = engaging
4 = engaged and vehicle stopped.
Regen On / Off On when regen braking is taking place;
Regen_State On / Off Off when it is not.
System_Flags1 [Bit 2]
0x322B 0x00
Master Timer
0 429496729.5 s The master timer is a timer of the total hours
Master_Timer O – 4294967295 the controller is powered on (keyswitch hours).
0x3160 0x00 The master timer is controlled by the OS
software and cannot be reset.
VCL Error Module
0 65535 A VCL Runtime Error (fault code 68) will
Last_VCL_Error_Module 0 – 65535 store additional information about the
0x3473 0x00 cause of a VCL runtime error in the VCL
VCL Error 0 – 65535
Error Module and VCL Error variables. The
Last_VCL_Error 0 – 65535
resultingnon-zerovaluescanbecompared
0x3472 0x00
to the runtime VCL module ID and error
codedenitionslistedinthecontroller’sOS
SysInfole,whichshouldhelppinpointthe
VCL error that caused the runtime error.
