4a — MONITOR MENU
Monitor Menu: MOTOR TUNING
DISPLAY
VARIABLE RANGE DESCRIPTION
Motor RPM -32768 – 32767 rpm Motor speed in revolutions per minute.
Motor_RPM -32768 – 32767
0x3207 0x00
Base Speed Captured 0 – 65535 rpm Displays the value of the motor base speed
Base_Speed_Captured 0 – 65535 captured in the most recent acceleration.
0x35BE 0x00
This value is used to set the FW Base
Speed parameter, using the FW Base Speed
set procedure described on page 57 or using
theACIMmotorcharacterizationprocedure
(Section 6a).
Test Field Current
0 – 800 A Field test current reading to be used during
Test_Field_Current 0–80 – 800000 theACIMmotorcharacterizationprocedure
0x3873 0x
00 (Section 6a).
Following Error
-12000 – 12000 rpm Signal error between the commanded
Following_Error 0–8-12000 – 12000000 motor speed trajectory and the actual
0x3555 0x
00 motor rpm.
Monitor Menu: CUTBACKS
DISPLAY
VARIABLE RANGE DESCRIPTION
Motor Temp Cutback 0 – 100 % Displays the current available as a result of
MotorTempCutback 0 – 4096 the motor temperature cutback function.
0x3581 0x00
A value of 100% indicates no cutback in
current.
Controller Temp Cutback
0 – 100 % Displays the current available as a result of
ControllerTempCutback 0 – 4096 the controller temperature cutback function.
0x35F3 0x00
A value of 100% indicates no cutback in
current.
Undervoltage Cutback
0 – 100 % Displays the current available as a result of
UndervoltageCutback 0 – 4096 the undervoltage cutback function.
0x3605 0x00
A value of 100% indicates no cutback in
current.
Overvoltage Cutback
0 – 100 % Displays the current available as a result of
OvervoltageCutback 0 – 4096 the overvoltage cutback function.
0x3604 0x00
A value of 100% indicates no cutback in
current.
