DGS-3100 Series Gigabit Stackable Managed Switch User Manual
92
The MLD Snooping Page contains the following fields:
Field Description
MLD Snooping
Enables or disables MLD Snooping. The possible field values are:
Enabled — Enables MLD Snooping on the device.
Disabled — Disables MLD Snooping on the device. (This is the default
value).
VLAN ID
Specifies the VLAN ID.
VLAN Name
Displays the user-defined VLAN name.
Done Timer
Specifies the time interval in seconds after which a port is removed from the
Multicast membership group. Ports are removed from the Multicast
membership when the port sends a Done Message, indicating the port
requests to leave the Multicast group. The field range is 0-16711450
seconds. The default timeout is 10 seconds.
Host Timeout
Specifies the time interval in seconds after which a port is removed from a
Multicast Group. Ports are removed if a Multicast group MLD report was
not received from a Multicast port within the defined Host Timeout period.
The possible field range is 60 - 16711450 seconds. The default timeout is
260 seconds.
Router Timeout
Specifies the time interval in seconds the Multicast router waits to receive a
message before it times out. The possible field range is 60 - 16711450
seconds. The default timeout is 300 seconds.
State
Indicates if MLD snooping is enabled on the VLAN. The possible field
values are:
Enabled —MLD Snooping is enabled on the VLAN.
Disabled —MLD Snooping is disabled on the VLAN. (This is the default
value).
Static Router Port Setting (Edit button)
Displays the MLD Snooping & Static Router Ports Settings Page.
Multicast Entry Table (View Button)
Displays the Multicast Entry Table.
2. Click . The MLD Snooping & Static Router Ports Settings Page opens:
