D-Link DGS-3100 SERIES User Manual

DGS-3100 Series Gigabit Stackable Managed Switch User Manual
200
Configuring PoE System Settings
The PoE System Setting Page contains port utilization information for specific ports. To view port statistics:
1. Click PoE > PoE System Setting. The PoE System Setting Page opens:
Figure 0-2 PoE System Setting Page
The PoE System Setting Page contains the following fields:
Fields Descri
p
tion
Unit
Defines the unit number.
System Power Threshold
Indicates the power in Watts consumed before an alarm is generated. The possible field
values are:
50W — Indicates 50 watts.
100W — Indicates 100 watts.
170W — Indicates 170 watts.
Disconnect Method
Defines the method used to deny power to a port once the threshold is reached. The
possible fields are:
Deny next port —Denies power to the next port that makes a PoE request after the
threshold has been reached. This is the default value.
Deny Low priority port—Denies power to the lowest-priority port after the threshold
has been reached.

D-Link DGS-3100 SERIES Specifications

General

Type	Managed
Layer	Layer 2+
Ports	10/100/1000BASE-T
SFP Ports	2 or 4 (depends on the model)
Additional SFP Ports	No
VLANs	Yes
Stacking	Yes, Physical Stacking
QoS	Yes
Jumbo Frame Support	Up to 9K bytes
Management	Web-based
Operating Temperature	0°C to 40°C
Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Model	DGS-3100 SERIES
Storage Temperature	-40°C to 70°C
