D-Link DGS-3100 SERIES User Manual

DGS-3100 Series Gigabit Stackable Managed Switch User Manual
186
Viewing MLD Group Information
The MLD Snooping Group Page contains vital MLD group information, including the Multicast Group IP address and the
corresponding MAC address through which the MLD packets passed.
1. Click Monitoring > MLD Snooping Group. The MLD Snooping Group Page opens:
Figure 6-114
MLD Snoopi
ng Group Page
The MLD Snooping Group Page contains the following fields:
Field Description
VID
Defines the VLAN ID for the MLD Snooping Group.
VLAN Name
Defines the VLAN name.
VLAN Name
Displays the currently selected user-defined VLAN name.
Multicast Group
Displays the IP address assigned to the Multicast group.
MAC Address
Displays the MAC address assigned to the Multicast group.
Port
Displays the ports where the MLD packets were snooped.
2. Define the VID and VLAN Name fields.
3. Click
. The MLD Snooping Group Page displays relevant information

D-Link DGS-3100 SERIES Specifications

General

Type	Managed
Layer	Layer 2+
Ports	10/100/1000BASE-T
SFP Ports	2 or 4 (depends on the model)
Additional SFP Ports	No
VLANs	Yes
Stacking	Yes, Physical Stacking
QoS	Yes
Jumbo Frame Support	Up to 9K bytes
Management	Web-based
Operating Temperature	0°C to 40°C
Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Model	DGS-3100 SERIES
Storage Temperature	-40°C to 70°C
