D-Link DGS-3100 SERIES User Manual

DGS-3100 Series Gigabit Stackable Managed Switch User Manual
70
Enabling Jumbo Frames
Jumbo Frame support is designed to enhance Ethernet networking throughput and significantly reduce the CPU utilization
of large file transfers like large multimedia files or large data files by enabling more efficient larger payloads per packet.
The Jumbo Frame Page al
lows network managers to enable Jumbo Frames on the device.
1.
Click L2 Features > Jumbo Frame. The Jumbo Frame Page opens:
Figure 0–1 Jumbo Frame Page
The Jumbo Frame Page contains the following field:
Field Description
Jumbo Frame
Defines whether Jumbo Frames are enabled on the device. The possible field values are:
Enabled — Enables Jumbo Frames on the device.
Disabled — Disables Jumbo Frames on the device. This is the default value.
2. Select Enable in the Jumbo Frames field. Jumbo Frames are enabled only after the configuration is saved and the
device is rebooted.
3. Click
. Jumbo Frames are enabled after the device is reset.

D-Link DGS-3100 SERIES Specifications

General

Type	Managed
Layer	Layer 2+
Ports	10/100/1000BASE-T
SFP Ports	2 or 4 (depends on the model)
Additional SFP Ports	No
VLANs	Yes
Stacking	Yes, Physical Stacking
QoS	Yes
Jumbo Frame Support	Up to 9K bytes
Management	Web-based
Operating Temperature	0°C to 40°C
Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Model	DGS-3100 SERIES
Storage Temperature	-40°C to 70°C
