D-Link DGS-3100 SERIES User Manual

DGS-3100 Series Gigabit Stackable Managed Switch User Manual
182
Viewing MLD Router Ports
The Browse MLD Router Port Page displays which ports are connected to MLD routers. A port can be connected to an
MLD router either as a static port or as a dynamic port or forbidden port.
1. Click Monitoring > Browse MLD Router Port. The Browse MLD Router Port Page opens:
Figure 0-10 Browse MLD Router Port Page
The Browse MLD Router Port Page contains the following fields:
Field Description
VID
Indicates the VLAN identification.
Unit
Indicates the stacking member for which the router ports information is displaying.
Port
Indicates the port for which the router port settings are displayed. Ports have the following
settings:
S — Indicates a statically configured port.
D — Indicates a dynamically learned port.
F — Indicates a forbidden port.
2. Define the VID field.
3. Click
. The selected ports appear on the selected VLAN.

D-Link DGS-3100 SERIES Specifications

General

Type	Managed
Layer	Layer 2+
Ports	10/100/1000BASE-T
SFP Ports	2 or 4 (depends on the model)
Additional SFP Ports	No
VLANs	Yes
Stacking	Yes, Physical Stacking
QoS	Yes
Jumbo Frame Support	Up to 9K bytes
Management	Web-based
Operating Temperature	0°C to 40°C
Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Model	DGS-3100 SERIES
Storage Temperature	-40°C to 70°C
