D-Link DGS-3100 SERIES User Manual

DGS-3100 Series Gigabit Stackable Managed Switch User Manual
7
MANAGING POWER OVER ETHERNET DEVICES
NOTE: This chapter is valid only when using devices
on which Power over Ethernet (PoE) is
supported.
Power over Ethernet (PoE) provides power to devices over existing LAN cabling, without updating or modifying the
network infrastructure. Power-over-Ethernet removes the necessity of placing network devices next to power sources.
Power-over-Ethernet can be used in the following applications:
 IP Phones
 Wireless Access Points
 IP Gateways
 Audio and Video Remote Monitoring
Powered Devices are devices that receive power from the device power supplies, for example IP phones. Powered Devices
are connected to the device via Ethernet ports. Guard Band protects the device from exceeding the maximum power level.
For example, if 400W is the maximum power level, and the Guard Band is 20W, if the total system power consumption
exceeds 380W no additional PoE components can be added. The accumulated PoE components power consumption is
rounded down for display purposes.
This section includes the following topics:
 Defining PoE Port Information
 Configuring PoE System
19
7

D-Link DGS-3100 SERIES Specifications

General

Type	Managed
Layer	Layer 2+
Ports	10/100/1000BASE-T
SFP Ports	2 or 4 (depends on the model)
Additional SFP Ports	No
VLANs	Yes
Stacking	Yes, Physical Stacking
QoS	Yes
Jumbo Frame Support	Up to 9K bytes
Management	Web-based
Operating Temperature	0°C to 40°C
Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Model	DGS-3100 SERIES
Storage Temperature	-40°C to 70°C
