xStack DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
Figure 7- 14. PVID Auto Assign Settings window
When Enabled, PVID will be automatically assigned when adding a port to a VLAN as an untagged member port.
MAC-based VLAN Settings
This table is used to create new MAC Based VLAN entries and search, edit and delete existing entries.
To view this window click L2 Features > VLAN > MAC-based VLAN Settings:
Figure 7- 15. MAC-based VLAN Settings window
The following fields can be set:
To configure a Double VLAN, enter the following parameters and click Apply.
Parameter Description
MAC Address
Specify the MAC address to be reauthenticated by entering it into the MAC Address field.
VLAN Name
Enter the VLAN name of a previously configured VLAN.
Click Find, Add or Delete All for changes to take affect.
129
