xStack DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
Side Panel Description
The system fans and heat vents located on each side dissipate heat. Do not block these openings. Leave at least 6 inches of space
at the rear and sides of the Switch for proper ventilation. Be reminded that without proper heat dissipation and air circulation,
system components might overheat, which could lead to system failure and severely damage components.
Figure 2- 13. Side Panels (DGS-3450)
Figure 2- 14. Side Panels (DGS-3426 and DGS-3427)
Figure 2- 15. Side Panels of the DGS-3426P
8
