xStack DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
To configure JWAC port settings for the Switch, click Security > JWAC > JWAC Port Settings, and click the Add button,
which will open the following window:
Figure 10- 48. JWAC Port Configuration window
To set the JWAC on individual ports for the Switch, complete the following fields:
Parameter Description
Port List
Lists the range of Ports that will be configured in this window.
State
This parameter specifies the state of the configured ports.
MAX Authenticating
Host
This parameter specifies the maximum number of host process authentication attempts
allowed on each port at the same time.
Aging Time
(1-1440 Minutes)
This parameter specifies the period of time a host will keep in authenticated state after it
successes to authenticate. Enter a value between 0 and 1440 minutes. The default setting is
1440 minutes. To maintain a constant Port Configuration, check the Infinite box in the JWAC
configuration window.
Idle Time
(1-1440 Minutes)
This parameter specifies the period of time during which there is no traffic for an
authenticated host and the host will be moved back to the unauthenticated state. Enter a
value between 1 and 1440 minutes. A value of Infinite indicates the Idle state of the
authenticated host on the port will never be checked. The default setting is Infinite.
Block Time
(0-300 Seconds)
This parameter specifies the period of time a host will keep in a blocked state after it fails to
authenticate. Enter a value between 0 and 300 seconds. The default setting is 0 seconds.
Click Apply to implement changes made.
To view the JWAC Port Table click on the hyperlinked Show JWAC All Ports Setting Entries, which will open the following
window:
243
