xStack DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
L2 Features – Contains the following menu pages and sub-directories: VLAN, Trunking, IGMP Snooping, MLD Snooping,
Loopback Detection Global Settings, Spanning Tree and Forwarding & Filtering.
QoS – Contains the following menu pages and sub-directories: Bandwidth Control, QoS Scheduling Mechanism, QoS Output
Scheduling, 802.1p Default Priority and 802.1p User Priority.
ACL – Contains the following menu pages and sub-directories: Time Range, Access Profile Table and CPU Interface Filtering.
Security – Contains the following menu pages and sub-directories: Authorization Network State Settings, Traffic Control, Port
Security, 802.1X, Trust Host, Access Authentication Control, MAC Based Access Control, Traffic Segmentation, SSL, SSH and
JWAC.
Monitoring – Contains the following menu pages and sub-directories: Device Status, Stacking Information, Module Information,
CPU Utilization, Port Utilization, Packets, Errors, Packet Size, Browse Router Port, Browse MLD Router Port, VLAN Status,
VLAN Status Port, Port Access Control, MAC Address Table, IGMP Snooping Group, MLD Snooping Group, Switch Logs,
Browse ARP Table, Session Table, IP Forwarding Table, Browse Routing Table and MAC Based Access Control Authentication
Status.
Save Services – Contains the following menu pages and sub-directories: Save Changes, Configure Information and Current
Configuration Settings.
Reset, Reboot System and Logout menu links are displayed in the main directory.
NOTE: Be sure to configure the user name and password in the User
Accounts menu before connecting the Switch to the greater network.
