xStack DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
Delete
Click the
button to delete this entry from the list.
To enter an IPv6 Interface into the IPv6 Static Route list, click the Add button, revealing the following window to configure.
Figure 6- 45. Static/Default Route Settings – Add menu
Click to select the default option if this will be the default IPv6 route. Choosing this option will allow the user to configure the
default gateway for the next hop router only.
The following fields can be set:
Parameter Description
Interface
The IP Interface where the static IPv6 route is to be created.
IPv6 Address/Prefix
Length
Specify the address and mask information using the format as IPv6 address / prefix length
(IPv6 address is hexadecimal number, prefix length is decimal number, for example
1234::5D7F/32).
Clicking the default check box will set the IPv6 address as unspecified and the Switch will
automatically find the default route. This defines the entry as a 1 hop IPv6 default route.
Next Hop Address
Enter the IPv6 address for the next hop Gateway address in IPv6 format.
Metric (1-65535)
The metric representing the number of routers between the Switch and the IPv6 address
above.
Click Apply to implement changes made.
77
