xStack
®
DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
125
After setting the previous parameters, click Apply to allow your changes to be implemented. Successfully created trunk groups
will be show in the Link Aggregation Group Entries window.
NOTE: To configure the Algorithm for Link Aggregation, please refer back to the DGS-
3400 Web Management Tool and select the Link Aggregation Algorithm located on that
web page. The description for this function may be found in the explanation for the
Device Information window located earlier in this manual.
LACP Port Settings
The LACP Port Settings window is used in conjunction with the Link Aggregation window to create port trunking groups on
the Switch. Using the following window, the user may set which ports will be active and passive in processing and sending LACP
control frames.
To view this window, click L2 Features > Trunking > LACP Port Settings, as shown below:
