xStack
®
DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
46
Status
Displays whether the entry is Active or Inactive.
Delete
Click the
button to delete this entry from the IPv4 Static/Default Route Settings table.
To enter an IP Interface into the Switch’s IPv4 Static/Default Route Settings window, click the Add button, revealing the
following window to configure:
Figure 2 - 41 Static/Default Route Settings – Add window
The following fields can be set:
Parameter Description
IP Address
Allows the entry of an IP address that will be a static entry into the Switch’s Routing Table.
Subnet Mask
Allows the entry of a subnet mask corresponding to the IP address above.
Gateway
Allows the entry of an IP address of a gateway for the IP route above.
Metric (1-65535)
Allows the entry of a routing protocol metric representing the number of routers between
the Switch and the IP address above.
Backup State
The user may choose between Primary and Backup. If the Primary Static/Default Route
fails, the Backup Route will support the entry. Please take note that the Primary and
Backup entries can not have the same Gateway.
Click Apply to implement changes made.
IPv6 Static/Default Route Settings
A static entry of an IPv6 address can be entered into the Switch’s routing table for IPv6 formatted addresses.
To view this window, click Administration > Routing Table > IPv6 Static/Default Route Settings, as shown below:
Figure 2 - 42 IPv6 Static/Default Route Settings window
This window shows the following values:
