xStack
®
DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
128
Figure 3 - 26 IGMP Snooping Settings – Edit window
The following parameters may be viewed or modified:
Parameter Description
VLAN ID
This is the VLAN ID that, along with the VLAN Name, identifies the VLAN the user
wishes to modify the IGMP Snooping Settings for.
VLAN Name
This is the VLAN Name that, along with the VLAN ID, identifies the VLAN the user
wishes to modify the IGMP Snooping Settings for.
Query Interval
The Query Interval field is used to set the time (in seconds) between transmitting
IGMP queries. Entries between 1 and 65535 seconds are allowed. Default = 125.
Max Response Time
This determines the maximum amount of time in seconds allowed before sending an
IGMP response report. The Max Response Time field allows an entry between 1 and
25 (seconds). Default = 10.
Robustness Variable
Adjust this variable according to expected packet loss. If packet loss on the VLAN is
expected to be high, the Robustness Variable should be increased to accommodate
increased packet loss. This entry field allows an entry of 1 to 255. Default = 2.
Last Member Query Interval
This field specifies the maximum amount of time between group-specific query
messages, including those sent in response to leave group messages. Default = 1.
Version (1-3)
Configure the IGMP version of the query packet which will be sent by the router.
Host Timeout
This is the maximum amount of time in seconds allowed for a host to continue
membership in a multicast group without the Switch receiving a host membership
report. Default = 260.
Route Timeout
This is the maximum amount of time in seconds a route is kept in the forwarding
