xStack
®
DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
131
Figure 3 - 29 IGMP Snooping Static Group Settings window
The following parameters can be configured:
Parameter Description
VID
The list of the VLAN IDs for which to create IGMP snooping static group information.
VLAN Name
The name of the VLAN for which to create IGMP snooping static group information.
IP Address
The static group address for which to create IGMP snooping static group information.
To search for an entry enter the appropriate information and click Find, to display all current entries on the Switch click View All.
To add a new entry click Add, the following window will be displayed.
Figure 3 - 30 IGMP Static Group Add window
Parameter Description
VID
This is the VLAN ID that, along with the VLAN Name, identifies the VLAN the user wishes to add.
VLAN Name
This is the VLAN Name that, along with the VLAN ID, identifies the VLAN the user wishes to add.
IP Address
The static group address for which to create IGMP snooping static group information.
PortList
The ports that will belong to this group.
Action
Specifies to Add or Delete the IGMP Static group entry.
Click Apply to implement changes made.
