xStack
®
DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
139
Figure 3 - 40 Router Port window (Modify)
The following parameters can be set:
Parameter Description
VID (VLAN ID)
This is the VLAN ID that, along with the VLAN Name, identifies the VLAN where the MLD
multicast router is attached.
VLAN Name
This is the name of the VLAN where the MLD multicast router is attached.
Member Ports
Ports on the Switch that will have a multicast router attached to them. There are four options for
which to configure these ports:
None – Click this option to not set these ports as router ports
Static – Click this option to designate a range of ports as being connected to a multicast-enabled
router. This command will ensure that all packets with this router as its destination will reach the
multicast-enabled router.
Forbidden – Click this option to designate a port or range of ports as being forbidden from being
connected to multicast enabled routers. This ensures that these configured forbidden ports will
not send out routing packets
Click Apply to implement the new settings.
