xStack
®
DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
199
Figure 5 - 20 Access Rule Table window (Packet Content Mask)
To remove a previously created rule, select it and click the button. To add a new Access Rule, click the Add button:
Figure 5 - 21 Access Rule Configuration window (Packet Content Mask)
To set the Access Rule for the Packet Content Mask, adjust the following parameters and click Apply.
Parameter Description
Profile ID
This is the identifier number for this profile set.
Mode
Select Permit to specify that the packets that match the access profile are forwarded by the
Switch, according to any additional rule added (see below).
Select Deny to specify that packets that match the access profile are not forwarded by the
Switch and will be filtered.
Select Mirror to specify that packets that match the access profile are mirrored to a port defined
