xStack
®
DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
22
Figure 2 - 12 Box Information window
Parameter Description
Current Box ID
The Box ID of the switch in the stack to be configured.
New Box ID
The new box ID of the selected switch in the stack that was selected in the Current Box ID field.
The user may choose any number between 1 and 12 to identify the switch in the switch stack.
Auto will automatically assign a box number to the switch in the switch stack.
Priority
Displays the priority ID of the Switch. The lower the number, the higher the priority. The box
(switch) with the lowest priority number in the stack is the Primary Master switch. The Primary
Master switch will be used to configure applications of the switch stack.
Information configured in this window is found in the Monitoring folder under Stacking Information.
NOTE: Configured box priority settings will not be implemented until users
physically save it using the Web GUI or the CLI.
