xStack
®
DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
44
Figure 2 - 38 IPv6 Neighbor Settings window
The following fields can be configured or viewed:
Parameter Description
Interface Name
Enter the interface name of the IPv6 neighbor you wish to find.
Neighbor IPv6
Address
Enter the neighbor IPv6 address of the entry you wish to find.
State
To find or delete specific entries use the pull-down menu to select either Static or Dynamic.
Static – Select Static to view all statically entered IPv6 neighbors on the Switch.
Dynamic – Select Dynamic to view all dynamically configured neighbor devices which are IPv6
neighbors of the IP interface previously created.
IPv6 Neighbor Settings
Neighbor
Displays the IPv6 address of the neighbor device.
Link Layer Address
Displays the MAC address of the corresponding IPv6 device.
Interface
Displays the Interface name associated with this IPv6 address.
State
Displays the running state of the corresponding IPv6 neighbor. The user may see six possible
entries in this field, which are Incomplete, Stale, Probe, Reachable, Delay or Static.
To remove an entry, click the corresponding Delete button. To completely clear the IPv6 Neighbor Settings, click the Clear All
button. To add a new entry, click the Add button, revealing the following window to configure:
Figure 2 - 39 IPv6 Neighbor Settings – Add window
The following fields can be set or viewed:
Parameter Description
Interface Name
Enter the name of the Interface associated with this entry, if any. The Interface field is
used for addresses on the link-local network. It is recommended that the user enter the
To Next Page
