88
An alarm is triggered only when size of the target that is crossing tripwire
lies between the two filter boxes.
When drawing a rule, you can select Maximum Size or Minimum Size and
click Clear to delete a relevant filter box.
4) For more tripwire settings, see the following table.
Table 4-23 More tripwire settings
Parameter Description
Direction
Configure the target moving direction for tripwire alarm, you can select A->B,
B->A and A<->B.
Alarm Track
Enable this function and when tripwire is triggered, the Camera will use
thermal lens or visual lens to track the object.
Track Time Time for the lens to track the object.
To set linked measures such as Audio Linkage and White Light when the tripwire rule Step 5
detects an object, see "4.4.10 Configure Linked Measures."
Click Save. Step 6
4.4.2.2.2 Intrusion
When a target is crossing or appears in the area you have set, an alarm is triggered.
Procedure
Select Setting > Smart Thermal > IVS. Step 1
The Rule Config interface is displayed.
Intelligent rules are set separately for thermal channel and visual channel. Decide the Step 2
channel and select it in the Channel selection bar.
Select a preset in Preset bar. Step 3
The camera turns to the position.
Set intrusion rules. Step 4
1) Click to add a rule. In the Rule Type column list, select Intrusion. In the Name
column, double-click a name, Rule2, for example, to define it. See Figure 4-45.
