7 Safe Fieldbuses
7.1 PROFIsafe
7.1.1 Introduction to PROFIsafe
This chapter describes the Advanced safety system when PROFIsafe is enabled and a PROFIsafe-capable fieldbus option board is
installed.
PROFIsafe is an additional safety protocol on top of a standard transmission system (PROFINET/PROFIBUS). PROFIsafe uses several
technologies to ensure the validity and status of the fieldbus communication, making it reliable to use with safety devices. These
measures include: consecutive numbering, watchdog time monitoring with acknowledgment, codename per communication rela-
tionship, and cyclic redundancy check for data integrity.
Communication over the non-safe transmission systems is called the "black channel".
Standard data Fail-safe data
PROFisafe layer
PROFisafe layer
Fail-safe data
Standard bus protocol
PROFIBUS DP / PROFINET IO
Standard bus protocol
Standard data
e30bi362.10
Illustration 68: PROFIsafe Communication
The Advanced safety option board supports version V2.4 of PROFIsafe in V2 mode. The PROFIsafe protocol can be used in applica-
tions with up to SIL 3 requirements according to IEC 61508 and the PROFIsafe communication is implemented according to IEC
61784-3.
7.1.2 The Requirements and Restrictions
To use PROFIsafe with the Advanced safety option board, the components of the table are required.
Table 43: The Required Components and Versions for PROFIsafe
Component
Version
Comment
The control board of the AC drive
System software: NXP00002V198 or newer
Hardware: Serial number 761 or newer
–
OPTE3/E5 PROFIBUS option board
Firmware: FW0083V006 or later
GSD file: Vac30CCF revision 2 or newer
–
The safety PLC
–
Must support PROFIsafe
OPTEA Advanced Dual Port Ethernet
Firmware FW0241V001 or later
–
AQ319736045637en-000101 / DPD01798 | 111Danfoss A/S © 2021.06
Safe Fieldbuses
VACON® NXP Advanced Safety Options
Operating Guide
